WISKA 818CUR Consumer Unit Relocation Kit
Material: Polycarbonate
Protection class: IP65
Temp. range min: -25 °C
Temp. range max: 85 °C
Glow wire test 650 °C
Impact resistance: IK08
External dimensions:
LxWxH 215x200x95mm
Type: CUR 818
Suitable for relocating up to 10 ways*
Fast self-tapping stainless screws
Terminals**
2202-1201 - Grey 2 conductor DIN-rail terminal with button push-in up to 4mm (x8)
2202-1204 - Blue conductor DIN-rail terminal with button push-in up to 4mm (x8)
2202-1207 - Green/Yellow 2 conductor DIN-rail terminal with button push-in up to 4mm (x8)
2002-1292 - Orange Endplate for 2202 (x1)
2210-1201 - Grey 2 conductor DIN-rail terminal with button push-in up to 16mm (x2)
2210-1204 - Blue 2 conductor DIN-rail terminal with button push-in up to 16mm (x2)
2210-1207 - Green/Yellow 2 conductor DIN-rail terminal with button push-in up to 16mm (x2)
2010-1292 - Orange Endplate for 2210 (x1)
*Each Final ring circuit need to be considered as 2 ways
**Wiska reserve the right to use alternative push-in terminals to the same standard should there be supply issues.
